Wires and cables GOST, TU, EAC Cable cross-section Cheating when selling cables
In the last video, I looked at how to choose the wire section, cable section and circuit breakers for electrical wiring. The wire size chart in this video is valid when using wires and cables that actually meet the stated specifications. Some electricians and salespeople cheat when selling and laying cables, using substandard materials. In rare cases, they do this because of their incompetence.
https://bit.ly/GD128PLR - Good multimeter
https://bit.ly/MtRuchR - Multimeter pen
https://bit.ly/IstPitR - Laboratory power supply
https://bit.ly/PlGVDAR - Professional soldering iron
https://bit.ly/StripKWR - Stripper for stripping wires
https://bit.ly/ElSanKan - Subscribe but my ZEN channel
https://bit.ly/Pomkan - Support the channel financially
• Сечение провода и сечение кабеля. Как выбр... How to choose the cable section and machines
• Сборка щита. Сколько автоматов ставить в к... The number of machine guns in the shield
http://bit.ly/el_sv_ruk The best electrical videos
00:00 - Cheating in the sale of electrical cable.
00:30 - What should electrical wires and cables correspond to? GOST, TU, EAC.
00:58 - What are specifications for electrical cables and wires?
01:21 - How to determine that the cable does not comply with GOST and EAC standards?
01:35 - What does it mean that the cable complies with GOST and EAC standards?
01:56 - Differences in wires according to TU and GOST standards.
02:58 - An example of using a low-quality cable of the TU standard.
03:24 - Who produces wires and cables TU?
03:37 - How to distinguish between a TU cable and a GOST or EAC cable?
03:50 - Where and how to buy a quality GOST or EAC cable?
04:34 - Correspondence table for wire diameter and section.
04:44 - The formula for converting diameter to cross section for wires.
05:00 - Is it worth buying a TU cable?
05:14 - Which installation cable do I recommend?
05:37 - Why is low-quality cable sold on the market and in stores?
05:58 - How can electrical wiring installers deceive a customer?
06:23 - Support the video about cheating when selling cable with like, repost, comment.
Wires and cables can comply with GOST, TU, EAC.
GOST is a state standardization. Came from the times of the Soviet Union.
TU - technical conditions. They are created by the manufacturer for the manufactured products.
EAC - Compliance with the regulations and requirements of the Eurasian Customs Union
Any cable or wire complies with specifications. These are the technical conditions according to which it was manufactured by the enterprise. But in order for it to comply with GOST or EAC, it must be certified for compliance with the technical requirements of these standards. If the cable or wire is produced with pre-decreased characteristics, then the manufacturer will not pass this certification and you will not find GOST or EAC badges on the wire tag.
Cables that comply with GOST or EAC do indeed meet the stated specifications. This is the cross section of the conductive wires, the material of the wires, the material and thickness of the insulation. It is these wires that I recommend for laying in your apartment or house.
Consider the differences between the wires TU and GOST (EAC). Each production writes technical conditions for itself. And as a result, the cross section of the wires can be underestimated by 20-30%. A cable with a cross section of 1.5 mm2 can be in real life a cross section of 1.1-1.3 mm2, and a cable with a cross section of 2.5 mm2 - a cross section of 1.8-2.0 mm2. Naturally, it is designed for a lower current, since the cross section of the cable cores is lower than stated.
The most interesting thing is that this is not a fake from China. These cables can be produced by the same enterprise, only one cable is TU, and the other cable is GOST. This can be seen on the cable tag. But sellers can change this tag.
How to insure yourself against buying substandard cable. Personally, I always buy cable in trusted places where they know me well. They sell cables and GOST and TU. I ask for a GOST cable - they sell it to me. It can be up to 30% more expensive. If you buy a cable - don't look for a cheaper cable - it's easy to run into a DUT cable.
