In this tutorial, we will look at How to make "Touch Switch Circuit using 555 timer" Step by Step completely
555 timer IC is an Integrated Circuit that can be used for so many different types of applications like Timer, Pulse generation, Oscillator, a Memory element, etc.
This simple Touch Switch is developed by using a 555 timer IC operated as a MONOSTABLE vibrator. Here the stable stage is LOW, so the timer outputs low after the trigger is removed. Basically, in this circuit, we will have an LED that turns ON when we touch a pin of timer. The LED will be ON for the time during which the trigger is present. Once the trigger is removed the LED turns OFF.
――――――――――――――――――――――
❖ Hardware Required ❖
――――――――――――――――――――――
+4 to +6 supply voltage
555 IC
470Ω, 100KΩ resistors
10µF, 100nF (104) capacitors
LED
Touch plates
―――――――――――――――――
