Issue 139. Assembling the Vise Control Mechanism. Universal Carpentry Machine. Part 12
This issue is dedicated to integrating a vise control mechanism into the machine's table frame as part of the development of Yashin's Universal Automated Flatbed Woodmachine (Yashin-11). The vertical axis will be computer-controlled. Movement along the longitudinal and transverse axes will be manual, and in the future, electronically controlled. This means that the machine being developed will not be a traditional CNC machine. In my opinion, such a machine is closer to the mindset of a hobbyist woodworker, as it offers greater technical possibilities for creativity.
Maximum milling parameters:
length - 2150 mm;
width - 1300 mm;
height - 400 mm.
The machine is based on the Woodro machine designed by Korean designer Lee Hyun.
Contents:
00:00 Introduction
01:05 Spacers for TP nuts
02:13 Installing TP screws into the holes in the table frame
02:37 Installing TP nuts on TP screws
03:24 Installing the BK20 bearing support
04:40 Installing the M20x1 lock nut
05:08 Installing the key into the TP shaft groove
05:13 Installing the pulley on the TP shaft
05:25 Securing the pulley with an M6 screw
05:40 Installing the pulley cap
05:44 Installing the BF20 bearing support
06:47 Installing the key into the TP shaft groove
06:54 Installing the toothed pulley on the TP shaft
07:18 Installing the toothed belt
07:44 Installing TP nuts with spacers on the jaw Vise
08:11 Checking the vise jaw movement
09:09 Adjusting the parallelism of the vise jaw to the side of the table frame
11:56 About stepper motors for vise jaw movement
12:23 Farewell
