ARDUINO IDE + ESP32 + TFT LCD | Upload Image File to ESP32 Via Web Server and Display on TFT LCD
***********************************************
Follow and contact me on Instagram : / utehstr
***********************************************
***********************************************
ARDUINO IDE + ESP32 + 3.2" TFT LCD Touchscreen ILI9341 240x320 + Web Server.
Upload Image File to ESP32 Via Web Server and Display on TFT LCD.
The maximum image resolution allowed on this project is : 320x240 px.
Software used :
Arduino IDE (V1.8.19).
Arduino core :
Arduino core for the ESP32 (V2.0.16).
Arduino libraries used :
TFT_eSPI by Bodmer (V2.5.43).
TJpg_Decoder by Bodmer (V1.1.0).
Hardware used :
ESP32 (ESP32 DevKit V1).
3.2" TFT LCD Touchscreen ILI9341 240*320 Pixel.
And other equipment such as cables, power supplies and others.
Timestamp :
00:00 Opening
00:28 Project Preview
02:06 Installation image
02:16 Step 1 - LittleFS Test
04:15 Step 2 - TFT LCD Test
05:36 Step 3 - Main Project (Station Mode)
08:20 Step 3 - Main Project (Station Mode) - Demo
12:52 Step 3 - Main Project (Access Point Mode)
15:52 Closing
***********************************************
Download the project files (program code files and other files) here : https://drive.google.com/file/d/1cHbR...
The code file is saved in the .rar file format. I created a .rar file using Winrar V5.50, so to extract it, make sure you use the same version of Winrar that I use or the latest version or use the winrar extractor online.
***********************************************
SORRY IF MY ENGLISH IS CONFUSING, I USE AN ONLINE TRANSLATOR.
THANKS FOR WATCHING & DON'T FORGET TO LIKE , SHARE, COMMENT AND SUBSCRIBE.
***********************************************
