Sonar sweep with polar plot | LabVIEW (LINX 3.0) with Arduino Uno
This video shows an example of a sonar with sweeping motion for detecting objects, based on angle and range, that then are displayed in a polar plot using LabVIEW LINX VI's with a Arduino Uno.
Components used:
Servo (E-SKY 8G)
Ultrasonic Sensor (HC-SR04)
Arduino UNO Rev3
If there are any questions regarding this video demonstration you can leave a comment in the comment section. For more helpful information, go to LabVIEW MAKERHUB:
https://www.labviewmakerhub.com
