Robot Packing PLC Program Development
The Machine Simulator (MS) is a valuable component of the EasyPLC software suite. It offers a range of built-in machines, including the robot packing machine, which effectively demonstrates various programming techniques. We will use the Click PLC programming software to showcase a sequencer application for this example.
In this scenario, the robot is tasked with collecting five bags and loading them into a cardboard box. A logical sequence of steps will be implemented to accomplish this, with a counter controlling the progression. This fundamental approach to programming sequences applies to all PLCs.
To program the EasyPLC robot packing machine simulator, we will use the free Click programming software and a Click PLUS PLC. Communication between the software and the PLC will be established using Modbus TCP (Ethernet). The program sequencer offers a convenient and efficient means of controlling the automation system.
We will follow the five program development steps to guide you through the process. These steps will provide a clear and structured approach to programming the sequencer. With that said, let's dive right in and begin our journey into the world of robot-packing PLC program development.
Our website post provides effortless access to all the relevant links discussed in the video. We have gathered all the necessary information for your convenience, to all the resources mentioned.
https://accautomation.ca/robot-packin...
00:00 Robot Packing PLC Program Development
01:36 Define the task: (Step 1 - Click Easyplc Robot Packing)
04:12 Define the Inputs and Outputs: (Step 2 - Click Easyplc Robot Packing)
05:58 Develop a sequence of operations: (Step 3 - Click Easyplc Robot Packing)
07:27 Develop the ladder logic PLC program (Step 4 - Click Easyplc Robot Packing)
13:47 Test the program: (Step 5 - Click Easyplc Robot Packing)
