How to Insert Emergency Lighting in Revit — PSCIP Template Families
How to use the PSCIP template emergency lighting families in Revit — ceiling and wall luminaires, with insertion in the floor plan, tag identification, and automatic quantification in the drawing table.
✅ How to access emergency lighting families in the Systems tab of Revit
✅ How to insert ceiling, wall, and floor lighting fixtures
✅ How to rotate and position lighting fixtures on the floor plan
✅ How to add an identification tag (TG) linked to the schedule
✅ How to automatically quantify all lighting fixtures on the project sheet
━━━━━━━━━━━━━━━━━━━━━━━
📌 VIDEO TOPICS
━━━━━━━━━━━━━━━━━━━━━━━
0:04 — Introduction: Emergency lighting family in the PSCIP template
0:39 — Systems tab in Revit: where the electrical, plumbing, and air components are located
0:49 — Inserting a bollard light fixture — types available in the template (ceiling, wall, floor)
1:08 — Positioning the light fixture on the floor plan and rotating it with the spacebar
1:32 — 3D View: visualizing the inserted light fixture model
1:57 — Light fixture quantification table: dragging it to the sheet
2:09 — Result on the sheet: symbology, type, and description automatically filled in
2:29 — Inserting a wall light fixture via Systems → Light Fixtures
2:52 — Inserting a ceiling light fixture — same symbol, different types
3:17 — Adding an identification tag (TG) and changing it to the correct type
3:47 — Copying light fixtures and verifying automatic updates in Table
━━━━━━━━━━━━━━━━━━━━━━━
