YAMAHA R15-S |2016| WALKAROUND RED
ENGINE
Engine type
Liquid-cooled, 4-stroke, SOHC
Displacement
149 cc
Maximum power
12.2kw@ 8,500rpm
Maximum torque
15N.m / 7,500rpm
Starting method
Electric start
Lubrication Type
Wet sump
Fuel tank capacity
12 liters
Fuel supply system
Fuel Injection
Clutch type
Wet, Multiple-disc
Transmission type
Constant mesh 6-speed
Battery
12V, 4.0AH (10H), sealed type
YZF-R15s
DIMENSIONS
Overall Length x Width x Height
2,060mm x 670mm x 1,070mm
Seat height
800 mm
Wheelbase
1,345 mm
Ground clearance
160 mm
Kerb weight
134 kg
CHASSIS
Frame type
Delta Box
Caster / Trail
26° / 98mm
Tire size (Front / Rear)
90/80-17 / 130/70-R17
Brake type
Single disc (Front / Rear)
Suspension type (Front / Rear)
Telescopic fork / Linked type monocross
Headlight
12V, 35.0W / 35.0 W x 2
LIQUID COOLED ENGINE
First Indian made model with liquid cooled Engine. Liquid Cooled Engine provide stable performance, reduce vibrations, and offer a high quality ride. The engine is surrounded by a water jacket in which coolant liquid circulates to cool the engine. While this method is widely used in automobiles and large capacity motorcycles, there are very few examples of motorcycles of this class due to increased weight from components such as radiators. YZF-R15s uses a special compact and lightweight aluminium radiator and a body design that utilizes airflow for heat dissipation. This has enabled us to create a lightweight, compact body while retaining its stable performance.
The benefits of using this method include stable performance during long-distance, high-speed riding and hill climbing. A liquid-cooled engine does not need heat-dissipating fins and therefore the engine is able to deliver its best performance without being affected by temperature. Additionally, because the head and cylinder are enclosed in a water jacket, mechanical noise from the engine is reduced dramatically. The newly developed engine delivers agile riding performance, and excellent performance on straight stretches of road as well as on winding roads. YZF-R15s also delivers excellent environmental performance. These traits are a must for an "urban supersport". The ride is unprecedented in terms of both excitement and quality.
UNIBODY SEAT
Unibody seat adopted to give more comfort for rider and pillion.
