OpenNest: #02 Nesting Rhino Objects with their Attributes | Objects' IDs
In this video, we learn how to nest objects for fabrication while maintaining their type, color, layers, and other attributes. We cover the Rhino Objects and Transform Guid components from OpenNest, review Globally Unique Identifiers (GUIDs) and the use of objects' IDs for nesting.
OpenNest 1.3.3 is a free open-source digital fabrication plugin for Grasshopper and Rhinoceros.
For more information about the "OpenNest" plugin and the developer, please visit: https://www.food4rhino.com/app/opennest
CHAPTERS:
00:00 Intro
00:38 Rhino Objects component in OpenNest
00:48 Objects' IDs | GUIDs
01:12 Reference Rhinoceros Objects as GUIDs in Grasshopper
02:35 Transform Guid OpenNest component
03:10 Changing nesting options or baking new objects with Transform Guid component
03:44 Closing
COMPONENTS:
"OpenNest" component
"Rhino Objects" component
"Transform Guid" component
LINKS:
Add-ons: https://www.food4rhino.com/
Forum: https://discourse.mcneel.com/
Grasshopper component library: http://grasshopperdocs.com/
CONTACT:
https://www.learn-visual-programming.com
Narrated by: Lina Vestarte
