Creating a Parametric Ramp with multiple segments in AutoCAD | Tip of the Month
The Parametric Ramp command allows you to quickly draw a parametric ramp composed of parallel segments and multiple curves. First begin creating your centerlines that will connect the bypass from the ramp, with the sloped needed in your operations. After that, start using the command, selecting the objects needed and give the specific parameters needed for your ramp and the command will automatically create it for you.
