[DIY Solution] Shorten that annoying 4.5m power cable! Replace the plug on the Furman SS-6B and c...
If you have any advice on smarter processing methods or precautions, please share them in the comments! 🌞 Processing power cables is dangerous and done at your own risk, so please do not try this at home.
I believe the biggest risks are shorting cables together during processing and cables coming loose after processing, so I think you should use crimp terminals even if it's time-consuming, troublesome, and expensive.
The Furman power distributor is a good product, but the power cable is extremely long at 4.5m for home use. If you're using it without processing, I recommend a 1U rack-mount type, as it has a shorter power cable.
[Workflow]
1. Cut the cable to the required length.
2. Peel the cable's outer jacket to expose the core wires (black, white, green/ground).
3. Crimp an appropriate size crimp terminal (e.g., R2-3.5) onto each core wire.
4. Check the polarity inside the plug (the white wire is in the "W" position) and re-secure each core wire with the screws.
⚠️ **Caution**: Modifying power cables is electrical work and can be dangerous. Proceed at your own risk or ask someone with specialized knowledge to do the work.
▼Tools and Materials Used
FURMAN Power Distributor, Black, SS-6B
https://amzn.to/3A7vNK1
Meiko Grounding L-Shaped Plug for Round Cords, ME7017
https://amzn.to/46uNz6d
Nichifu Terminal Industry Crimping Tool, Overall Length 235mm, NH 1
https://amzn.to/3SwuHOv
Nichifu Terminal Industry Bare Crimp Terminals for Copper Wire (Round), 20-Pack, HC R-2-3.5
https://amzn.to/4ccospO
---
🎥 Video Chapters
[00:00:00] Opening: Furman SS-6B and the Problem of Too Long a Cable
[00:01:14] Power Plug (Meiko) Used Introducing the ME7017
[00:01:38] Preparing the ground pin (thin pin) to fit a household outlet
[00:03:37] Measuring and cutting the cable
[00:04:47] Stripping the cable's outer sheath and insulation
[00:06:05] Why and how to shorten the ground wire (green)
[00:08:55] Twisting the core wire
[00:09:48] Crimping the crimp terminal (R2-3.5)
[00:13:20] Connecting and securing the core wire inside the plug
[00:15:19] Adjusting the size and reconnecting (readjusting the ground wire)
[00:17:26] Assembling the plug body and tightening the screws
[00:20:01] Checking contact with a tester and completing the process
---
