Diy Arduino Based Mini CNC Plotter Machine Using Arduino UNO R3, L293D Motor Driver and DVD Rom
This is a Homemade Arduino Based Mini CNC Plotter Machine. CNC means Computer Numerical Control. This machine can automatically draw any image. It is automatically controlled by Computer and can draw image using the X, Y, Z coordinates. Now a days, CNC is very popular in industry. It is very helpful to cut wood, cloth, steel and anything in any design. In this video i have shown a demo CNC machine which can draw image. For making this CNC Machine i have used the following components:
Arduino UNo R3
L293D Dual DC Motor Controller
Stepper Motor
Old DVD Rom
I have made the frame using Wood and Screw. To Run this CNC Machine we need to connect our CNC machine with our computer via USB cable. We also some software to operate this CNC Machine.
