Hik Vision DVR Dual Monitor Output setup for Live View Layout
This video are demonstrate how we able configure the 2 video output interface
"VGA/HDMI" is 1 video output
"CVBS/Channel" 0 is 1 video output
We able to organize the output layout and specific camera view on specific video output.
Material included:
Hik Vision DVR : iDS-7216HQHI-M2/S (Make sure the DVR support CVBS output)
HDMI Monitor
CYBS Monitor "the using RCA connector (Yellow, Red, White jack)
