ESP32 connected via Ethernet
Example of a simple home automation application to demonstrate the capabilities of the ESP32-ETH01 or WT32-ETH01 boards, which allow an ESP32 to communicate directly via Ethernet.
It includes:
pressure and temperature measurement with a DHT22
brightness measurement with an LM393
motion detection with an SR505
a flashing LED
a watchdog to monitor proper operation
a partial sleep mode to save energy
a web server to display the results
periodic reporting to an external server
OTA (Over The Air) updates
The source software and installation details are provided on the website http://f1atb.fr/fr home automation section.
The same video in English: • ESP32 connected via Ethernet
