G-Code for an Arduino plotter
I covered how to assemble a CNC plotter in a previous video. • ЧПУ плоттер на Arduino своими руками Today, we'll look at the process of creating G-Code for an Arduino plotter, from finding an image to creating a finished engraving. We'll use several programs for this: Inkscape, Carbide Create, and Candle. To create the engraving, you'll need to draw a vector image yourself or find a ready-made drawing online.
You can download all the materials from the project page:
https://cnc-tex.ru/news/18/g-code-dly...
