clear all
%% ~~~ Read the provided input .wav file
%-----------------------------------------------------
[Input_wav,Sample_Frequency] = audioread('Input.wav');
Input_wav = Input_wav./max(abs(Input_wav));
% ~~~ Play the input .wav ~~~~
soundsc(Input_wav,Sample_Frequency)
Input_Length = size(Input_wav,1);
Playbacktime = Input_Length/Sample_Frequency;
pause(Playbacktime) % Pause further coding for the duration
%-----------------------------------------------------
%% ~~~ Convolution Reverberator ~~~~
%------------------------------------------------------
%~~~ Input Impulse response
disp(' Enter the impulse time Impulse time(second)')
Impulse_position(1) = input('');
disp(' Enter the impulse Amplitude')
Impulse_position(2) = input('');
%- Generate the impulse Response
Imp_response = zeros(size(Input_wav,1),1);%Impulse
% Generate impulse train
Imp_response(Impulse_position(1)*Sample_Frequency) = Impulse_position(2);
% plot the input waveform
subplot(2,1,1);
hold on
plot((((1:Input_Length) -1)/Sample_Frequency),Input_wav,'b');
xlabel('Time (seconds)')
ylabel('Amplitude')
%--------- Convolution operation------------------------------
Reverber_length = length(Input_wav) + length(Imp_response) - 1;
F_input = fft(Input_wav, Reverber_length) ;
F_impluse = fft(Imp_response, Reverber_length);
Output_wav = ifft(F_input.*F_impluse);
Output_wav = Impulse_position(2).*(Output_wav./max(abs(Output_wav)));
%-------------------------------------------------------------
% plot the Reverberator waveform
plot( (((1:size(Output_wav,1))-1)/Sample_Frequency),Output_wav,'r');
title('Reverberated Signals')
subplot(2,1,2);
plot((((1:Input_Length) -1)/Sample_Frequency),Imp_response,'m');
xlabel('Time')
ylabel('Amplitude')
title('Impulse Response');
%% ------- play and Write a .wav file-----------------
Output_wav(1:Input_Length) = Output_wav(1:Input_Length) + Input_wav(1:Input_Length);
sound(Output_wav,Sample_Frequency)
audiowrite('output.wav',Output_wav,Sample_Frequency);
