Hello friends,
this is the video tutorial about using the LDR sensor.
The Schematic/ Circuit Diagram is in the Video.
For 2 volts
for 5 volts
and for 12 volts
Requirements
1 x LDR Sensor
1 x PNP or NPN Transistor
1 x LED
1 x 10K Resistor
1 x 1 K or 200R , depend to the input Voltage
