Array Math in the Horner OCS
Is data logging a regular part of your machine control or machine monitoring workflow? If so - you may have a need to perform math function on a data series or an array of data values. Join us for this Livestream as we show you how you can quickly and easily perform array math operations to find the Average, Minimum, Maximum and more.
To view the Cscape demo used in this video, click here: https://hornerautomation.com/wp-conte...
For more information, please visit: https://hornerautomation.com/
For Cscape information, or to download a FREE copy, visit: https://hornerautomation.com/cscape-s...
For other Horner Live Q & A - Software/Firmware Events - check out our playlist - • LIVE Q & A - Software/Firmware
Table of Contents:
00:00 - Intro
01:06 - Agenda
01:34 - What is Array Math?
02:41 - What is it Used for?
04:49 - Introduction to Cscape Array Math UDFBs
08:13 - Median_INT Flowchart
09:03 - Cscape Demo
11:24 - Median UDFB Test - Bench Demo
12:57 - Sum of Values
13:50 - Sum_INT Flowchart
14:32 - Average of Values
15:15 -Ave_INT Flowchart
15:38 - Sum & Ave UDFB Test - Bench Demo
16:48 - Min or Max Value
18:59 - Min_INT or Max_INT Flowchart
19:30 - Min & Max UDFB Test - Bench Demo
20:38 - Standard Deviation
22:56 - Std_Dev_INT Flowchart
23:42 - Standard Deviation UDFB Test - Bench Demo
24:37 - Review of Recent UDFBs
26:08 - Wrap-Up
