How to use eMMC SOCKET by GSMKEY
Visit our website for more details: http://www.gsmkey.com
Order eMMC Socket : http://www.gsmkey.com/emmc-socket-wit...
*DETAILS:
eMMC BOOSTER Feature:
eMMC Booster Tool is a new programmer for direct recording eMMC memory chips via the adapter or direct connection to the motherboard. It enables you to read/write User area of eMMC Chipsets. It provides high speed supporting 8 bits with compatible adapters .eMMC Booster Tool integrates a high speed microprocessor and a high efficiency hardware engine for the best data transfer performance between USB and eMMC interfaces. It supports mobile phones in-system programming and provides required eMMC voltages.Plug and Play hardware engine enables connectivity of outside eMMC adapters with 8 bits full speed of USB standards.
eMMC Booster Tool Features:
Re-programming the chip
Replacement of a damaged chipset
Repairing boot failure
Reading plain data for further investigation
Mobile phone forensics
High-speed USB 2.0 data transmission
Complies with 480Mbps USB specification rev. 2.0
Operating frequency: 60 MHz
12 clocks per instruction cycle
eMMC Booster Tool Supports:
ISP (In-System Programming)
ICP (In-Circuit Programming)
eMMC connection with adapter (Chip-off)
SD card connection (Direct SD)
Booster Tool Hardware:
Secure Digital and MultiMediaCard
Supports SD specification v1.0 / v1.1 / v2.0
Supports MMC specification v3.X / v4.X / v5.0 / v5.1
eMMC SOCKET Future:
Durability and Precise Connectivity
Wide Range Of Devices
Designed by Professionals
Magic Grid 4 in 1
Cost Effective
Supported Devices List and eMMC / eMCP Packages
You can easily connect to any device with the universal pinouting system with the eMMC Socket with following hardwares and magic grid currently provides connections to following IC packages .
#eMMC Pro #BGA 153
#eMMC Booster #BGA 162
#Medusa Pro Box #BGA 169
#Easy JTAG Box #BGA 186
#Easy JTAG Box 2 #BGA 221
#UFI Box #BGA 529
#GPG eMMC Box
#ATF Box
Package Inculede:
eMMC BOOSTER x 1 Pieces
eMMC SOCKET x 1 Pieces
Bridge Cable x 1 Pieces
4 in 1 PCB x 1 Pieces
eMMC SOCKET Carry Bag x 1 Pieces
Frame for different IC package x 5 Pieces
