[ $4 ] DIY eurorack modular synth VCF - Diode ladder low pass filter

Опубликовано: 24 Июль 2026
на канале: HAGIWO

23,206

596

My 39th original eurorack modular synth DIY projects.
4-pole diode ladder low pass filter. It has the characteristics of a thick and warm sound.
The concept is to make it with low cost, few parts, and easily available parts.

working documents ( schematics )
https://note.com/solder_state/n/n598f...

Please support me to continue projects.
  / hagiwo

DIY $6 SSM2044 type VCF
   • [ $6 ] DIY modular synth VCF V2044 based /...

-------------------------------------------------------------
See Instagram and Twitter for the development status of my next module.
