IEC61850 Station | Digsi 4: How to Import & Export Files (Step-by-Step Tutorial)
Learn how to seamlessly import and export configuration files in Siemens DIGSI 4 for IEC61850 substation automation projects! This tutorial covers SCL files (SCD, CID, IID), project backups, and device configurations to streamline your workflow.
🔍 In This Video, You’ll Learn:
Exporting Files from DIGSI 4:
Exporting IEC61850 SCL files (SCD, CID) for device interoperability.
Saving project backups (.dpa files) and device configurations (.def files).
Generating reports (.xml/.pdf) for documentation.
Importing Files into DIGSI 4:
Importing SCL files (CID from IEDs, SCD from system configurators).
Restoring project backups and device configurations.
Integrating third-party device descriptions (.icd files).
Key Tools Used:
DIGSI 4 "Station" manager for system-level exports.
"Device" mode for IED-specific imports/exports.
"File" menu shortcuts & drag-and-drop workflows.
⚙️ Helpful Commands:
Export SCD: Station Manager - Right-click station - Export - SCL (SCD)
Import CID: Device Navigator -Right-click device - Import - SCL (CID)
Project Backup: File Save As (creates .dpa backup)
how to import and export file from IEC61850 station
How to Create IEC 61850 file
• How to Create IEC 61850 Station & Files in...
#IEC61850 #Digsi4 #SubstationAutomation #SCLFiles #SCD #CID #EngineeringTutorial #Siemens #ProtectionRelay #SmartGrid
