Tutorial PREPARE DRAWINGS IN REVIT FOR PRESENTATION | TACTICAL DRAWING | EASY / FAST Visual Quality
I teach you to prepare your plans through the concept of technical visual quality, something we call, tactical drawing. Here we will see how to configure the weight of the lines, the visualization of values, qualities or thicknesses of those lines and the hatches and textures in a plant, a section and a facade. We will also see the possibilities of creating templates to apply to your other views and thus present your plans in a professional and technical way in your project presentation.
Leave your comments below and tell us what you think about this tutorial.
SUBSCRIBE AND FOLLOW US ON
Facebook / architeklab
Instagram / architeklab
Twitter @architeklab
Software
Autodesk Revit 2021
https://www.autodesk.com
