thread milling operation on vmc || vmc programming

Опубликовано: 27 Июль 2026
на канале: CNC VMC TECHNOLOGY (SAJWAN SIR)

24,858

422

in this video i am going to show you how to milling thread on holo pipe or external or internal thread on solid material, types of threading tools and part program for dim-54 mm part thread depth 15 mm and pitch 1.5 mm.
how to calculate value of j and i on the circle. i and j is offset values for distance of start point of circle to the centre of the circle in x-axis and end point of the circle to the centre of the circle in y axis, called i, and j offset values.
