Autodesk Construction Cloud Viewing Revit Files
Are you working with Revit and the Autodesk Construction Cloud, especially using the cloud worksharing functionality (BIM Collaborate Pro)?
Then there are a number of things you should be doing as best practice to help optimise and improve performance when working with your cloud work shared models.
In this video, we can have a look at the Autodesk Construction Cloud and how to leverage viewing 2D and 3D views from Revit files within the web browser.
First of all, we need to make sure in the correct project inside docs and files they will find a project folder that will have a Revit File in it.
Top tips for creating and working on our Revit models saved in the cloud (Autodesk Construction Cloud)
.
Groups – Avoid using groups where possible.
Model Lines – Replace model lines with detail lines.
Warnings – Regularly review and resolve warning messages.
Room Separation Lines – Minimise the number of room separation lines as much as possible.
Linking Files – Always link files instead of importing files and don’t bind in linked files. Reduce the number of loaded linked files such as DWG and RVT files. Only load the files you are working on.
Views – Deleting all the unnecessary views created within the model. If it is not needed then why is it there?
Close Hidden Windows – Do not have too many view windows open at once. When you update a model Revit updates and regenerates the model across all those views of which the elements are displayed. This may only be a split second or a few seconds but can save you time waiting for it to regenerate.
Families – limit the detail they are modelled, nested families and parameters attached to families. Do not insert DWG into a Revit family model instead.
Restarting Revit – It is good practice to restart Revit before performing memory-intensive operations, such as printing entire document sets.
For more information on Autodesk Construction Cloud please visit our https://www.pentagonsolutions.com/pro... or contact us using the details below.
