Let's Build Tronxy X5SA 500 Pro Part 6
In this part of the series of videos I am covering step 10 through step 13. This includes the feeding motor, switches, some cosmetics and reinforcements as well as connecting the wires.
Step 10 describes the installation of the feeder(titan extruder clone) and the filament run out sensor.
Step 11 is about the end stop switch and the filament holder.
In step 12 the baby blue aluminium profile seal and end caps are installed. Also the reinforcements for torsion forces are installed.
Step 13 is the final step which shows how to connect the wires.
0:00 Introduction and off camera mods
3:06 Step 10 Feeder
11:35 Step 11 End stops and holder
22:00 Step 12 Cosmetics and reinforcements
32:25 Step 13 Wiring
39:48 Closing words
