FNIRSI LCR P1 Any Good?
In this video we evaluate the FNIRSI LCR-P1 Component tester. It was hoped that it might be an improvement on the older component testers like the TC1 used for comparison in this video. However, the LCR-P1 with firmware 1.05 has many bugs and also cannot identify many components that the older testers can identify correctly.
This video ended up longer than expected but we go in detail with semi-conductors and capacitors. The "Chapters" section below has the locations of the various sections and tests in case you wish to skip to them.
Equipment Used:
FNIRSI LCR-P1 Component Tester: https://www.aliexpress.us/item/325680...
MESR-100 ESR Meter: https://www.aliexpress.com/item/32539...
Rigol Oscilloscope: https://www.amazon.com/gp/product/B08...
RuoShui 4090 Digital Benchtop LCR Meter: https://www.aliexpress.us/item/325680...
TC1 Component Tester: https://www.aliexpress.us/item/325680...
Atlas DCA75 Pro: https://www.newark.com/peak/72-12840/...
Chapters:
0:00 Intro
1:59 Features
2:57 Atlas DCA75 Pro as reference
4:14 Component Testing / Comparison
5:44 LED
6:25 Speed Test
7:36 Germanium Transistor (Inaccurate)
12:39 Dual Diode T0220 package (Fail)
16:50 Dual Schottky Diode (Fail)
19:40 Old glass silicon diode (Fail)
21:40 AC126 Germanium Transistor (Fail)
24:05 7805 Voltage Reg. (Only DCA-Pro could read)
25:44 Zener Diode
28:14 High Voltage Zener (Only LCR-P1 could read it)
29:28 J-FET
30:29 Uni-junction Transistor (None could read)
31:15 Thyristor (SCR) (Fail)
32:52 Triac (Fail)
34:57 Small IGBT (Fail)
37:28 Large IGBT
39:08 Capacitors Section
42:23 LCR-P1 Testing waveforms
46:40 MESR-100 ESR meter waveforms for comparison
49:30 ESR Discussion / Measuring with the LCR Meter
55:37 Measuring a standard electrolytic 100 uF/35 V
57:09 100 uF/16V
58:11 Solid AL 100 uf capacitor
1:00:33 Conclusion
