Homemade AC Voltage Detector ⚡
➡️10 High-Quality PCBs for $5: https://www.pcbway.es/
In this project, we'll make a voltage detector or phase detector (non-contact voltage tester). To do this, we'll use a pencil. At the end, we'll leave the normal writing function and add the AC voltage detection function.
➡️PCBway End-of-Year Promotions: https://www.pcbway.com/activity/chris...
➡️Electrical Diagram: https://drive.google.com/drive/folder...
➡️Facebook: / raom.electronica
➡️Instagram: / raomelectronica
➡️Electrical, Electronics, and Mechatronics Group: / 523663111800730
➡️Materials:
3 x C945 Transistors
1 x 27A Battery
1 x 1K ohm 1/4 W Resistor
1 x 100 ohm 1/4 W resistor
-1 x 5 mm LED diode
-1 x 104 ceramic capacitor
