STM32F4-Discovery kit as simple VGA controller (No SPI, No DMA, Full software)
STM32F4-Discovery kit as simple VGA controller (No SPI, No DMA, Full software)
Download source file: http://www.cncdesigner.com/STM/VIDEO.rar
I wrote two program but i dont remenber the VGA connections
First connection
VGA 1 ------ 100 Ohm --------- STM324F D12,
VGA 5 -------- Gnd STM324F
VGA 13 -------- STM324F D13
VGA 14 -------- STM324F D14
Other connection
GPIOD 8-9-10 (8 Video), (9 HS), (10 VS)
I use KEIL
