Model
HUANANZHI B660-D4 Motherboard
Main chipset
Intel B660
CPU Socket
Support Intel's 12th 13th generation LGA1700 platform processor
Memory slot
2 x DDR4 memory slot
Memory standard
Support Dual channels DDR4 3200/2933/2666/2400MHz Memory(Depends on CPU/supports XMP)，Max support 64 GB
Storage interface
4 x SATA 3.0 6Gbps
Expansion Slots
1 x PCI Express 4.0/5.0x16 ，1 x PCI Express 3.0 x4
Expansion interface
2 xM.2 22110 NVME PCIE X4 4.0
Soud Track
Realtek High Fidelity Audio
Network Card
Realtek Gigabit network card RTL8111GUS
Power interface
24PIN+8PIN
FAN PIN
1xCPU_FAN PIN，2xSYS_FAN PIN
power supply
8-phase power supply
PCB layers
4-layer PCB
Dimension
235*195MM M-ATX
Rear panel interface
4xUSB3.0 Interface，2xUSB2.0 Interface，1x VGA Interface，1x HDMI Interface，1x DP Interface，1x Network card interface，1x3-hole audio interface
Front panel interface
1 x USB2.0 PIN，1 x USB3.0 PIN，1 x Front audio pin，1 x COM PIN，1 x TPM PIN
Support system
Windows10 Windows11
BIOS
AMI UEFI Graphics BIOS
