Theory. Lesson 9.2 MSDRFT | Proportional Crown | Intersect Flanges | Explicit Control.
#Aliasmodeling, #Multi-Surface Draft, #MSDRFT, #Aliassurface, #Proportionalcrown, #intersectflanges, #explicitcontrol
Let's break down one of the most used tools in Alias Surface, Multi-Surface Draft. The Multi-Surface Draft tool uses surface edges, surface curves, isoparametric curves, and in Draft mode even free curves to create planar and non-planar surfaces (or groups of surfaces) that are angled to the original surface (or curve).
In this video we will look at Proportinal Crown settings (Crown Value, Crown Shape, Crown Type), Intersect Flanges, Explicit Control ( U degree, V degree, Spans, Segmentation option, Fitting method)
