HUMMINBIRD 110 IT WORKS !!!!
useing the HUMMINBIRD 110 FISHIN BUDDY today an it paid off works great specs below
https://www.humminbird.com/Products/1...
Display Size - Diagonal:4"
Display Pixel Matrix:128H X 160V
Display Type:FSTN LCD
Display Colors Grayscale:4 Level Grayscale
Sonar Standard:Single Beam
Standard Sonar Coverage:34° @ -10db
Standard Sonar Frequency:200 kHz
Sonar Optional:None
Target Separation:2.5"
Power Output RMS:125 Watts
Power Output Peak to Peak:1000 Watts
Depth Capability:240 ft Down
Temperature:Built In Transducer
Speed:Not Supported
Backlight:LED
Unit Size - Gimbal Mount:4.22"W x 5.76"H x 2.72"D
Mount A Type:Portable Clamp
Mounting Options:Portable Clamp
Transducer Standard:Fixed Pole
Transducer Mounting:24" Fixed Pole
Power Input:6 AA
Power Draw:110mA
GPS Receiver:Not Supported
GPS Tracking:Not Supported
GPS Chartplotting:Not Supported
Humminbird Mapping:Not Supported
Navionics+:Not Supported
Navionics Platinum+:Not Supported
Platinum Capable:Not Supported
C-Map 4D:Not Supported
360 Imaging:Not Supported
i-Pilot Link:Not Supported
HD Radar:Not Supported
NMEA 2000:Not Supported
5 Port Expansion Module:Not Supported
WeatherSense:Not Supported
Precision GPS:Not Supported
Heading Sensor GPS:Not Supported
PC Connect:Not Supported
External GPS Receiver:Not Supported
AS Interlink:Not Supported
AIS Compatability:Not Supported
SwitchFire Sonar:Not Supported
Screen Snap Shot:Not Supported
Sonar Recording:Not Supported
Upgradable Internal Software:Not Supported
Split Screen Zoom:Not Supported
Split Screen Bottom Lock:Not Supported
3D Chart View:Not Supported
Large Digits View:Not Supported
Wide/Narrow Cone Split Screen:Not Supported
Custom View Selections:Not Supported
Custom Digital Readout:Not Supported
View Preset Keys:Not Supported
Temperature Graph:Not Supported
Temperature Alarm:Not Supported
Freeze Frame:Not Supported
Instant Image Update:Not Supported
Mark Structure on Sonar:Not Supported
Selective Fish ID+:Included
Real Time Sonar:Not Supported
Triplog:Not Supported
X-Press Menu System:Not Supported
Card Reader Available:No
