How to DIY Oscilloscope Mini DSO with STC MCU Easily
Project information on Instructables:
https://www.instructables.com/id/Make...
Source Code on GitHub:
https://github.com/CreativeLau/Mini-DSO
Last Time, I shared how to make a
Function Generator With MCU. Some friends said they do not have an oscilloscope yet.
The video of How to make Function Generator with MCU:
• How to Make Function Generator with MCU to...
Today, I want to share you how to make a
simple Oscilloscope with MCU.
The core component is STC8A8K64S4A12 MCU. Using a SSD1306 OLED as display.
Hope you like it.
Please subscribe and support me.
