Police Light DIY with NE555 - PCB Tutorial
■ JLCPCB Prototype for $2(Any Color): https://jlcpcb.com
In this video we see a simple circuit, based on two NE555 that is able to reproduce the effect of the lights of the Police Cars, all made on a fantastic white PCB.
After trying the excellent service offered by JLCPCB I recommend it, the quality of the PCB is high, customer service is always available and professional, the time of realization is short and the delivery of PCBs is by express courier. JLCPCB is a great place to get hight quality custom circuit boards at an extremely low price, you can buy 5 PCB Boards (Any Color) for 2$ !!!
More About JLCPCB: https://support.jlcpcb.com/collection...
Components:
2x NE555
4x LEDs 5mm
2x 850 KΩ Resistors
1x 1uF @ 25V Electrolytic Capacitor
1x 100nF Polyester Capacitor
PCB: (Ready for jlcpcb.com): http://bit.ly/2ZeyDsL
*Don't use my PCB for profit or sponsored videos.
This circuit must be powered with 9V DC
Circuit Diagram: 0:32
Gerber Files (Ready for jlcpcb.com): http://bit.ly/2ZeyDsL
*You can see the complete procedure to upload the Gerber file on jlcpcb.com in the video from 1:52
**JLCPCB have a Technical Support for exporting Gerber files from many software at this link: https://support.jlcpcb.com/category/2...
For any other questions you can ask me for explanations in the video comments:)
