Fuji On Delay Timer Connection | On Delay Timer Connection with Contactor | On Delay | Fuji Timer

About this Video
Friends, in this video, I go into full detail about the Fuji On Delay Timer.
In this video, we explain the timer's common, NO, and NC points. After that, we understand the timer's coil. Then, I make connections that supply two contactors from the timer. I live-stream and demonstrate how our common point, NO point, and NC point work.

I also discuss what multi-range timing is.

Fuji timer terminals details
👇
• Fuji timer full details turminal | fuzi ti...

Fuji timer how to make more color less
👇
• fuji super timer multi-range type st3p | f...
