LS122 IR power meter With +/- 10% Accuracy
LS122 IR power meter With +/- 10% Accuracy
LS122 infrared power meter is an infrared powermeasuring instrument, which is used for measuring the infrared radiation luminance. Its unit is Watt persquare meter (W/m2). The instrument is also used for the infrared transmittance measurement.
TheStructure and Parameters of LS122
1. Irradiance measuring range: 0 -40000 W / m2
2. Accuracy: ± 10%
3. Relative intensity: 0 - 9999%
4. Spectral range: λ (1000-1700 nm); λp = 1400 nm
5. Detector Diameter: ¢ 10mm
6. Dimensions: 125mm × 69mm × 24.5mm (L× W × H)
7. Weight: around 140 grams (includingbattery)
8. Operating temperature: 20 ° C -- +70 ° C
9. Power supply: 4 pieces of AAAalkaline batteries
