SC-300 SUMWIC Silicon Strip Cutting Line with Automatic Stacker
http://www.sumwic.com (manufacturer)
email: [email protected]
SC-300 is designed and built for cores of small transformers such as
Inverters and UPS that made of Grain Oriented or Non-Grain Oriented
Silicon Steel to cut 90° shapes (Strip Laminations).
1) Model: SC-200/SC-300
2) Material: Thickness=0.18-0.35 mm, Width=25-300mm
3) Hole Size: Φ8-25mm
4) Max. Speed: 200m/min.
5) Accuracy: ±0.02mm
6) Max. Coil OD: 1200mm
7) Decoiler Capacity: 2000kg
8) Low Operating Cost: Tooling and Maintenance
