Discrete Logic Rhythm Game Prototype (no CPU)
Add a breadboard controller with D-Pad and health display to our project and, except for built-in music, we have a rhythm game! We need to press the controller buttons in time with symbols scrolling down the display. Make a mistake and the health bar shrinks. When there's no health left the clock is halted.
Music: Different Heaven by Nekozilla • Different Heaven - Nekozilla | Electro | N...
Controller breadboard: 2x 74LS163, 6x switches and blue LEDs
Health bar breadboard: 1x 74LS154, 4x 74LS08, 1x 74LS163 (on central board), 15x red LEDs
