DIY Make Powerful CNC Machine at Home - Part 2: Z-Axis Assembly and Tuning
In this video part see the following:
Z-Axise assembly based on MGN12C carriages and ball screw SFU1204 along with the DSG12H nut fixing
Fixing Z-Axis spindle plate
This machine based on linear motion combination between SFU1204 Ball screw and MGN12 Linear guides. I used also variety of aluminum extrusion profiles like 15180, 2080, 2040 and 2020. Additionally to 8mm thickness aluminum plates to fix them all.
Also don't miss the other parts
Watch Part 1: • DIY Make Powerful CNC Machine at Home - Pa...
Watch Part 3: • DIY Make Powerful CNC Machine at Home - Pa...
Excited to work on the next video parts and complete this machine very soon
