How To Use EasyEDA, A Free Circuit Simulator
How to build and simulate circuits with EasyEDA is discussed in detail. First, a basic resistor LED circuit is built and the voltage and current values are measured with a multimeter. Second, a 4-bit calculator circuit is simulated. Finally, an Astable Multivibrator is simulated for ten seconds and the output is shown on a logic analyzer and on an oscilloscope.
0:00 Intro
0:38 How to launch the program
1:59 How to build a circuit
6:23 4-bit calculator simulation
7:55 Astable Multivibrator simulation
9:55 Open source projects
11:04 Backup and save projects
11:31 LTspice for the next video
