How to simulate the HALF ADDER ?
In this video NI Multisim 14.0 have been used for all circuit SIMULATION.

Half Adder performs the addition of 2-bits.
• Truth Table:
x y C S
0 0 0 0
0 1 0 1
1 0 0 1
1 1 1 0

• Simplified Equation:
S= x'y+xy'
C=xy

• Digital Circuit:
Function: Component:
• QUAD 2-INPUT AND - 7408J
• QUAD 2-INPUT XOR - 7486N
• Red Probe - Digital Node Input - PROBE_DIG_RED
• Interactive Digital Constant - INTERACTIVE_DIGITAL_CONSTANT

• Digital Symbol:
Function: Component:
• Red Probe - Digital Node Input - PROBE_DIG_RED
• Interactive Digital Constant - INTERACTIVE_DIGITAL_CONSTANT
• HALF_ADDER - HALF ADDER
