How to create walls with BlenderBIM? Crazy gable walls and trims edition!
🏠 Dive into the world of BlenderBIM as we tackle the challenge of creating walls in BlenderBIM! 🌟 In this tutorial, we'll explore the intricacies of modeling a single-family house with its unique gables and trims.
💡 OK! Maybe you've dabbled in BlenderBIM before, but creating walls can leave you with more questions than answers. Can BlenderBIM handle the stress test of modeling a house? Will we have a quality IFC model by the end? Join me as we uncover the answers together!
🔨 Here's what we'll cover:
1️⃣ Creating walls in the floor plan for precise modeling.
2️⃣ Emphasizing the importance of maneuvering around your 3D Cursor for efficiency.
3️⃣ Crafting a gable wall by tweaking wall geometry and using Blender's knife tool for precision.
4️⃣ Building roof fascia, wall sweeps, and frieze boards from scratch, including face creation, flipping, and using modifiers to solidify shapes – all while assigning them IFCBuildingProxy class.
5️⃣ Placing corner boards with the Create Element BlenderBIM tool for added detail.
🔍 Did Blender and BlenderBIM pass the test? They did! Join me as we navigate through this tutorial and witness how BlenderBIM simplifies complex designs with ease.
👉 Ready for the challenge? Stay till the end and discover the power of BlenderBIM in creating stunning architectural designs effortlessly! Don't miss out – hit that subscribe button for more BlenderBIM adventures! 🚀✨ #BlenderBIM #ArchitecturalDesign #IFCModeling #BlenderTutorial #3DModeling #Architecture #BIMWorkflow #youtubetutorial
00:00 You created your first walls with BlenderBIM!
00:47 Welcome back!
01:23 Create your walls in floor plan
04:03 Adjust walls location
05:52 Adjust the wall joints
06:32 Edit your façade walls to create your gables
12:45 Creating the roof fascia and assign it as a IFCBuildingElementProxy Class
24:39 Create wall sweep and assign it as a IFCBuildingElementProxy Class
27:21 Create frieze and assign it as a IFCBuildingElementProxy Class
32:03 Create corner boards with the Create Element BlenderBIM tool
34:06 So did BlenderBIM pass the test?
34:46 You made it!
