Printed Circuit Board (PCB) fabrication is a complex process that requires substantial time and money investment. Very often it's done in a hurry without due diligence to Design for Manufacturability (DFM). The results can be devastating, and in this video I review 10 common issues with DFM and PCB design process in general, that can make all the difference between a good working design and a recycle bin.
TIMELINE:
00:00 - Start
00:52 - 1. Know Your Limits!
02:31 - 2. Board Layer Stack
06:10 - 3. Avoid via in pad!
08:55 - 4. Footprint mistakes
10:15 - 5. Mixing Through Hole and SMD
12:15 - 6. Provide enough clearance
14:52 - 7. Mismatched Length / Impedance
20:25 - 8. Add plenty of test points!
22:06 - 9. Segregate the PCB into areas
22:59 - 10. Take your time!
