3d structural drawing demo | Simple 5-minute CAD walkthrough
Welcome to part 2! This video demonstrates how to create columns and footings as part of a 3D structural drawing in CAD
The tutorial covers key steps such as adjusting the Z-height, selecting appropriate beam shapes, and utilizing the move and mirror commands to accurately place columns.
This video is part of a series that aims to help viewers create 3D structural drawings in CAD, focusing on constructing a detailed landing platform.
