Frictional head loss testing demonstrator/Fluid mechanics equipment
Hydraulics and hydromechanics apparatus series
frictional head loss apparatus
Experimental facilities:
Boundary dimension: length*width*height (cm) 160*50*220
Equipped equipment: 250W 220V 50HZ low noise stainless steel water pump， equipped with voltage regulator, to ensure water supply head constant (about 11 m) during the whole experiment process.
Pressure stabilizing box: material PVC diameter 40, height 34(cm)
Storage tank dimension: （cm）72×45×36
on-way resistance tube adopt stainless steel material, diameter 10mm, length 1500mm
The relationship between Linear head loss coefficient λ and Renolds value Re can be make from liminar flow to turbulent flow smooth area.
Measuring tape precision: 1mm, measuring tape height: 1200mm
Pressure gage, diameter 100mm 0.25MPa
