High-Frequency PWM with Arduino/ATmega HW Timers for driving SMPS
In this video we'll explore the option of using a hardware timer to generate the necessary PWM for driving a boost converter.
In a future video I intend to complete this project by creating a closed loop feedback system using the ADC and timer interrupts to create periodic sampling and correction.
Check out PCBWay: https://www.pcbway.com/
And their electronics design contest: https://www.pcbway.com/activity/7th-p...
0:00 Intro
0:32 Setting the timer mode
1:14 Setting Output Compare mode
1:51 Setting the Clock Prescaler
2:14 Setting Output Pin
2:27 PCBWay
3:17 Testing on Boost Converter
4:25 Frequency Setting
4:56 Outro
