Magazines To Get Your SMD Components Organized!
You're making your own PCBs at home?
At one point you'll end up having a box full of components strips.
If you want to purchase ready made magazines you can do so here:
https://shop.robins-tools.com/
To organize these I created these little magazines.
They'll boost your placement productivity and keep your shop organized 😊
You find detailed Instructions, STL Files, Drawings, BOM and a Fusion 360 Project on Thingiverse.
UPDATE: I've just released a version with a compliant mechanism design. No screws and springs needed! Details on thingiverse.
https://www.thingiverse.com/thing:395...
I hope you find this project interesting. If you do, please leave a thumbs up.
Twitter: @robin7331
Here's a link to MaxInt's original design: https://www.thingiverse.com/thing:218...
See you next time!
