3D Printed Ball Balancing Robot | PID Controlled Using LABview (2022)
----------------------------------------------------------------------
Outline: This video highlights how I built a custom 3D printed Ball-Balancing Platform using the Labview Software. Completed as an end of the Semester Project for a class titled Computer Methods at Bethel University, this project utilizes the PID (Proportional-Integral-Derivative) algorithm which is based on the difference of errors. Constructed out of PETG plastic, a 7" resistive touchscreen overlay paired with its signal adapter from Adafruit, two MG995 servo motors, and miscellaneous hardware, the system effectively prevents the ball from ever falling off the platform by actively and proactively adjusting the tilt angle to redirect the ball to the center.
If you have any questions, feel free to leave a comment!
For more info check out the links below.
------------------------------------------------------------------------
Project Materials
MG995 Servo Motors (4 pack): https://amzn.to/3tdfpRS
7” Adafruit Resistive Touchscreen: https://www.adafruit.com/product/1676
Adafruit 4-pin Touchscreen Breakout Adapter: https://www.adafruit.com/product/3575
Black PRILINE PETG Filament: https://amzn.to/3x9iQdJ
----------------------------------------------------------------------
PLEASE CONSIDER SUBSCRIBING: www.youtube.com/channel/UCCO6yWDiaUbL...
THE REST OF MY CHANNEL: https://www.youtube.com/channel/UCCO6...
-----------------------------------------------------------------------
***If you would like to monetarily support my channel to help fund future projects, or gain exclusive access to CAD files and specific project information, I invite you to become a Patreon member by clicking the link below.
Patreon: / matthewcarlsen
Patreon is a creators workplace where anyone can support people like artists, designers, and creators by signing up to generously give anywhere from $1 to $25 per month to makers. Through these donations, it provides opportunities to creators like me to help with funding of their passions while providing special content in return.
-----------------------------------------------------------------------
