Tank Project Modelling the Feets
For best experience watch the Video in Full HD!
The Tank Modelling Project is divided into 6 Videos.
This is the 4th of this Series.
In the "Modelling the Feets" Video you learn how to extract the contour Line of the Feets out of the PointCloud and use the Revolve along Object and Arraypolar Command to create a 3D Solid Model of it.
You can work afterwards with the created Model with your usual Workflows like Shell or Boolean Operators to finish the Tank. For this make sure that you use the Explode Command to split up the Array into 4 single Feets again.
Intro and Preparation:
• Tank Project Intro and Preparation
3D Modelling of the Tank Mantle:
• Tank Project 3D Modelling of the Tank Ma...
Modelling the Crown:
• Tank Project Modelling the Crown
Modelling the Feets:
Active Now
Modelling of a Horizontal Tank
• Tank Project Modelling of a Horizontal Tank
Modelling the Piping
• Tank Project Modelling the Piping
Following Equipment was used for 3D Laser Scanning:
FARO Focus 3D X330
http://www.faro.com/products/3d-surve...
FARO SCENE
http://www.faro.com/products/faro-sof...
The real Tank is made of highly reflective Material (polished chromium steel).
Following Software was used for working with the PointClouds:
Autodesk AutoCAD 2017
http://www.autodesk.com/products/auto...
FARO PointSense Plant
http://gb.faro3dsoftware.com/CAD/Prod...
Recorded with Camtasia
About PointSense: Video 1-4 uses only commands you find in all PointSense Products including PointSense Basic. Some Commands in Video 5 and 6 utilizes the extended Command Set which requires minimum PointSense Pro.
For more Details contact FARO directly.
